2 06B0003 washer Washer 9 GB93-10
3 00B0029 bolt Blot 9 GB5783-M10x20
4 06B0049 washer Washer 9 GB96-10
5 26B0010 oil cup Grease cup 9 JB / T7940.1-M10X1
6 15D0192 Pin Pin 1 -
7 82A0212 pipe clamp Spacer 4 -
8 06B0027 washer Washer 8 GB97.1-8
9 15D0191 Pin Pin 2 -
10 06B0009 washer Washer 8 GB93-8
11 00B0018 bolt Blot 8 GB5783-M8X25
12 15D0337 pin Pin 2 -
13 83A0991 reinforced fork jam plate The nameplate 1 -
14 15D0338 Pin Pin 2 -
15 34A0588 Sleeve Bearing 2 -
16 22D0456 folder on the fork upper part of the grapple 1 -
17 15D0339 Pin Pin 2 -

1 06C0588 hose Hose 1
3 06C0587 hose Hose 1
2 10C0224 left clip wooden cylinder Cylinder 1
4 06C0860 transition out of the oil pipe hose Hose 2
5 17D0880 transition Pipe Tube 2
6 10C0225 wood right gripper cylinder Cylinder 1
7 06C0589 hose Hose 1
8 06C0590 hose Hose 1

XG918
1 22D0458 lower clamp fork assembly nether part of the grapple 1 -
2 82A0211 pipe clamp Spacer 2 -
3 06B0009 Washer Washer 2 GB93-8
4 00B0018 bolt Blot 2 GB5783-M8X25
5 07B0179 collar Ring 4 GB894.1-45
6 60A0584 pin Pin 2 -
7 83A0992 clip Mucha nameplate The nameplate 1 -
8 54A0824 Sleeve Bearing 2 -
Clip fork assembly on the upper part 9 22D0459 of the grapple 1 -
10 26B0010 oil cup Grease cup 6 JB / T7940.1-M10X1
11 60A0583 Pin Pin 2 -
12 07B0063 collar Ring 8 GB894.1-35
13 60A0582 Pin Pin 2 -
1 10C0455 wood right gripper cylinder Cylinder 1 YG1235_MIR
3 06C0872 clip small wooden cylinder chamber hose Hose 1 13 / 14II-520 (0x90H50)
2 06C0871 clip large wooden cylinder chamber hose Hose 1 13 / 14II-630 (0x90H50)
4 06C0860 transition out of the oil pipe hose Hose 2 16 / 16II-1400 (0x90H80) jacket
5 17D1382 Pipe Tube 2 -
6 06C0607 clip large wooden cylinder chamber hose Hose 1 13 / 14II-630 (0x90H50)
7 06C0608 clip small wooden cylinder chamber hose Hose 1 13 / 14II-520 (0x90H50)
8 10C0454 left clip wooden cylinder Cylinder 1 YG1235
1 22D0481 lower clamp fork assembly nether part of the grapple 1 -
2 82A0211 pipe clamp Spacer 2 -
3 06B0027 Washer Washer 2 GB97.1-8
4 00B0018 bolt Blot 2 GB5783-M8X25
5 06B0009 Washer Washer 2 GB93-8
6 15D0362 pin Pin 2 -
7 15D0361 Pin Pin 2 -
8 54A0824 Sleeve Bearing 2 -
9 22D0486 fork upper clamp assembly upper part of the grapple 1 -
10 83A0993 circular clip Mucha nameplate The nameplate 1 -
11 15D0363 Pin Pin 2 -
12 26B0010 oil cup Grease cup 6 JB / T7940.1-M10X1
13 06B0049 washer Washer 6 GB96-10
14 06B0003 washer Washer 6 GB93-10
15 00B0028 bolt Blot 6 GB5783-M10x25
1 10C0224 left clip wooden cylinder Cylinder 1
3 06C0872 clip small wooden cylinder chamber hose Hose 1
2 06C0871 clip large wooden cylinder chamber hose Hose 1
4 06C0860 transition out of the oil pipe hose Hose 2
5 17D1382 Pipe Tube 2
6 06C0607 clip large wooden cylinder chamber hose Hose 1
7 06C0608 clip small wooden cylinder chamber hose Hose 1
8 10C0225 wood right gripper cylinder Cylinder 1
1 22D0284 quick bucket Bucket 1 -
2 83A1189 quick bucket (standard configuration) Nameplate The nameplate 1 -
3 43C0280 hydraulic quick change frame Hydraulic shortcut frame 1 -
1 10C0292 quick-change cylinder Cylinder 1
2 54A0436 Sleeve Bearing 2 -
3 60A0352 Pin Pin 2 -
4 20A1177 board Armor plate 1 -
5 11A0590 board Armor plate 2 -
6 00D0799 quick-change rack Shortcut frame 1 -
7 15D0237 Pin Pin 2 -
8 00B0019 bolt Bolt 5 GB5783-M8X15
9 00B0018 bolt Bolt 2 GB5783-M8X25
10 07B0294 collar Washer 2 GB894.1-25
11 06B0009 washer Washer 5 GB93-8
12 06B0027 washer Washer 7 GB97.1-8
13 26B0010 oil cup Grease cup 2 JB / T7940.1-M10X1
1 03B0619 Nut Nut 12 GB6185-M16
2 06B0014 washer Washer 12 GB97.1-16
3 72A0217 Bucket Teeth Teeth 6 -
4 00B1004 square head bolts Bolt 12 GB8-M16X60
5 22D0291 front bucket body Front part of the bucket 1 -
6 15D0250 pin Pin 2 -
7 00B0029 bolt Bolt 6 GB5783-M10x20
8 06B0003 washer Washer 6 GB93-10
9 06B0049 washer Washer 6 GB96-10
10 54A0445 Sleeve Bearing 2 -
11 22D0290 after fighting body Back part of the bucket 1 -
12 43C0280 hydraulic quick change frame Hydraulic shortcut frame 1 -
13 26B0010 oil cup Grease cup 6 JB / T7940.1-M10X1
14 15D0249 Pin Pin 2 -
Four in 15 83A0994 quick bucket nameplate The nameplate 1 -
16 15D0251 Pin Pin 2 -
1 10C0232 clip wooden cylinder Cylinder 2 YG818
2 06C0385 left folder tree large cylinder chamber hose Hose 1 13 / 14II-450 (90H70x90) 90
3 06C0384 left small clip wooden cylinder chamber hose Hose 1 13 / 14II-400 (90x90) 90
4 33C0356 quick couplers Shortcut joint 2 CNV082-2015F
5 17D1019 quick-change frame steel Tube 1 -
6 17D1018 quick-change frame steel Tube 1 -
7 33C0356 quick couplers Shortcut joint 2 CNV082-2015M
8 06C0386 right gripper cylinder small wooden chamber hose Hose 1 13 / 14II-400 (90x90) 270
9 06C0387 right gripper large wooden cylinder chamber into the oil hose Hose 1 13 / 14II-450 (90H70x90) 270
1 22D0293 clip fork assembly upper part of the grapple 2 -
2 54A0447 Sleeve Bearing 4 -
3 60A0369 Pin Pin 4 -
4 07B0063 retainer ring 8 GB894.1-35
5 26B0010 oil cup Grease cup 8 JB / T7940.1-M10X1
6 22D0292 clip Mucha base nether part of the grapple 1 -
7 83A0955 quick clip Mucha nameplate The nameplate 1 -
8 00B0022 Bolt Bolt 2 GB5783-M10x30
9 06B0003 Washer Washer 2 GB93-10
10 06B0004 Washer Washer 2 GB97.1-10
11 15D0252 Pin Pin 2 -
12 43C0280 hydraulic quick change frame Hydraulic shortcut frame 1 -
13 07B0018 retainer ring 4 GB894.1-30
14 60A0371 Pin Pin 2 -
1 10C0223 clip wooden cylinder Cylinder 2 YG816
2 06C0385 hose Hose 1
3 06C0384 hose Hose 1
4 33C0356 quick couplers (MALE) Hose fitting 2
5 17D1019 Pipe Tube 1
6 17D1018 Pipe Tube 1
7 33C0356 touch fitting Hose fitting 2
8 06C0386 hose Hose 1
9 06C0387 hose Hose 1
1 22D0294 carriage assembly Back part of the device 1 -
2 00D0860 fences Back stop 1 -
3 83A0978 quick fork nameplate The nameplate 1 -
4 06B0020 washer Washer 4 GB93-16
5 00B0061 bolt Bolt 4 GB5783-M16X45
6 06B0014 washer Washer 4 GB97.1-16
7 74A0019 3.0T Fork Prong 2 B3FSD-CLIIIA-JD × 30122
8 00B0014 bolt Bolt 1 GB5783-M12X20
9 43C0280 hydraulic quick change frame Hydraulic shortcut frame 1 -
10 18A0310 stopper plate 2 -
1 22D0295 bucket Bucket 1 -
2 83A0997 quick feed bucket nameplate The nameplate 1 -
3 54A0449 Sleeve Bearing 4 -
4 07B0018 retainer ring 8 GB894.1-30
5 60A0373 Pin Pin 2 -
6 26B0010 oil cup Grease Cup 8 JB / T7940.1-M10X1
7 07B0053 retainer ring 8 GB894.1-40
8 60A0372 Pin Pin 4 -
9 60A0407 Pin Pin 2 -
Gripper 10 22D0296 upper part of the grapple 2 -
11 43C0280 hydraulic quick change frame Hydraulic shortcut frame 1 -
1 06C0369 hose Hose 1 10 / 10I-1020 (0x90 G14H120)
2 06C0370 hose Hose 1 10 / 10I-1035 (0x90 G14H90)
3 10C0226 left feed cylinder Cylinder 1 YG918IIS
4 33C0356 touch fitting Hose fitting 2 CNV082-2015F
5 17D1019 quick-change frame steel Tube 1 -
6 17D1018 quick-change frame steel Tube 1 -
7 33C0355 quick couplers (MALE) Hose fitting 2 CNV082-2015M
8 10C0228 the right feed cylinder Cylinder 1 YG918IIS_MIR
9 06C0373 hose Hose 1 10 / 10I-1035 (0x90 G14H90)
10 06C0372 hose Hose 1 10 / 10I-1020 (0x90 G14H120)
1 06C0369 hose Hose 1
2 06C0370 hose Hose 1
3 10C0226 left feed cylinder Cylinder 1
4 33C0356 touch fitting Hose fitting 2
5 17D1019 quick-change frame steel Tube 1
6 17D1018 quick-change frame steel Tube 1
7 33C0355 quick couplers (MALE) Hose fitting 2
8 10C0228 the right feed cylinder Cylinder 1
9 06C0373 hose Hose 1
10 06C0372 hose Hose 1
1 22D0323 lower clamp fork assembly nether part of the jaw 1 -
2 07B0053 collar ring 8 GB894.1-40
3 60A0372 Pin Pin 4 -
4 83A0998 quick clip bark fork nameplate The nameplate 1 -
5 54A0449 Sleeve Bearing 4 -
6 26B0010 oil cup Grease Cup 8 JB / T7940.1-M10X1
7 07B0018 retainer ring 8 GB894.1-30
8 60A0373 Pin Pin 4 -
9 22D0324 fork upper clamp assembly upper part of the jaw 2 -
10 43C0280 hydraulic quick change frame Hydraulic shortcut frame 1 -
1 06C0432 hose Hose 1
2 06C0431 hose Hose 1
3 10C0255 cylinder Cylinder 1
4 33C0356 touch fitting Hose fitting 2
5 17D1019 quick-change frame steel Tube 1
6 17D1018 quick-change frame steel Tube 1
7 33C0355 quick couplers (MALE) Hose fitting 2
8 10C0256 cylinder Cylinder 1
9 06C0433 hose Hose 1
10 06C0434 hose Hose 1
