Model:50-03
Send Inquiry
| 50-03 brushless DC booster pump for pipe | ||||||||||
| ||||||||||
| Model Character | 50-03 | |||||||||
| Working voltage range | 6VDC-24VDC | |||||||||
| Max-static water head | 2.5-9±10% | |||||||||
| Max-static flow rate | 8-18L/min±10% | |||||||||
| Life span | Continuous operation under normal working condition≥20000 hours | |||||||||
| Working environment | Environment temperature＜25℃;PH value: PH5-10;It should work on land(non submersible). | |||||||||
| Max noise | Continuous operation under normal working condition(Measures from 1meter distance between the pump noise body to the test equipment)＜50db±10% | |||||||||
| Max working temperature | (aqueous solution)fluid medium temperature＜70℃ | |||||||||
| Application | Car shower, Pipe pressurization, Solar water heater,water shower, footbath,water coolant of home appliance and machines, washing machine, Solar water circulation system, small fountain,small aquarium, flower and plant watering, irrigation for small field,ect. | |||||||||
| Structure | Protection category | Inlet | Outlet | Remarks | ||||||
| Length(mm) | Width(mm) | Height(mm) | OD(mm) | ID(mm) | OD(mm) | ID(mm) | Inlet and Outlet have twistlock | |||
| 105 | 57 | 80 | IP66 | 20 | 14 | 20 | 14 | |||
