Model:MT82
Detailed introduction to Six-speed manual transmission-MT82:
The transmission is one 6-speed manual longitudinal type, which is developed and manufactured by introducing German technology. It can be used on medium & high class commercial cars, etc.
The transmission is a full synchronizer manual transmission with six forward speeds and one reverse speed. We have also incorporated a three-cone synchronizer assembly for 1st & 2nd gears, and a dual synchronizer assembly for 3rd & 4th gears, this increase ease of operation and the lifespan of the synchronizers All gears are grinded after heat treatment.
| Gear ratio | 6MTI500-L1 | 6MTI500-L2 | 6MTI500-L3 |
| 1st gear | 5.441 | 4.236 | 3.658 |
| 2nd gear | 2.839 | 2.538 | 2.431 |
| 3rd gear | 1.721 | 1.665 | 1.686 |
| 4th gear | 1.223 | 1.238 | 1.314 |
| 5th gear | 1.000 | 1.000 | 1.000 |
| 6th gear | 0.794 | 0.792 | 0.651 |
| Rev | 4.935 | 3.842 | 3.318 |
| Max torque | 385Nm~500Nm | ||
| Mounting length | 630 mm |
|
|
| Shifting mode | Cable shifting |
| |
| Central distance | 82 mm |
| |
| Application | Passenger cars (MPVs, SUVs, etc), commercial cars |
| |
