Detailed introduction to SAE J1508 Stainless Steel Worm Drive Hose Clamp:
SAE J1508 Stainless Steel Worm Drive Hose Clamp
1)bandwidth: 12.7mm Thickness:0.6mm
2)diameter :18-32mm
3) Installation Torque : 4.0-5.1N.M, Ultimate torque6.8 N.M
4)The hose clamp material different, its corrosion resistance is also different. Customers can choose a suitable hose clamps according to their practical application.
| KHxx | KHxxSS | KHFxxSS | KHLxxSS | |
| Material for Band | AISI 200 Series SS | AISI 200 Series SS | AISI 300 Series SS | AISI 316 SS |
| Material for Housing | AISI 200 Series SS | AISI 200 Series SS | AISI 300 Series SS | AISI 316 SS |
| Material for Screw | Carbon Steel | AISI 200 Series SS | AISI 300 Series SS | AISI 316 SS |
| Detail | Heat-treated, double-plated with zinc plus trivalent chromate. | |||
| corrosion resistance | ordinary | good | better | best |
| Rated Ultimate Torque | 50in.lbs. min.(5.6Nm) | 60in.lbs. min.(6.8Nm) | 60in.lbs. min.(6.8Nm) | 60in.lbs. min.(6.8Nm) |
| Recommended Installation Torque | 30-40in.lbs.(3.4-4.5Nm) | 35-45in.lbs.(4.0-5.1Nm) | 35-45in.lbs.(4.0-5.1Nm) | 35-45in.lbs.(4.0-5.1Nm) |
