Model:AC10
Send Inquiry
Detailed introduction to Integrated Roof Mounted Mini Van Bus Air Conditioner:
1.Integrated roof mounted unit
2.Fashionable styled streamline appearance
3.Abundant cooling capacity with kow noise
4.Proactive service,reasonable price and long life products
5.Special for Sprinter,Ford,Fiat,Renault,VW,IVECO etc van,ambulance vehicles
Techinal datas:
| Model | AC05 | AC10 | AC12 |
| Cooling capacity | 17060BTU(5KW) | 34120BTU(10KW) | 40944BTU(12KW) |
| Voltage | DC12V/24V | DC12V/24V | DC12V/24V |
| Current | 15A(24V) | 25A(24V) | 24A(24V) |
| Blower air vol | 600m3/h | 2000m3/h | 2200m3/h |
| Fan air vol | 1800m3/h | 2700m3/h | 3800m3/h |
| Compressor | SD5H14 | TM21 | DKS22/TM21 |
| Dimensions | 743*735*190mm | 1020*970*180mm | 1520*1100*174mm |
| Refrigerant | R134a | R134a | R134a |
| Suit for vehicles | 4.5-5m mini bus,van or 7-9seatsmini bus | 55-6m mini bus,van or 11-17 seats mini bus | 6-6.5m mini bus,van or 19-23 seats mini bus |
