Detailed introduction to Drop Center Rear Axle:
| Drop Center Rear Axle | |
| Model | CH132 |
| Nominal Load(Kg) | 13000 |
| Wheel Tread(mm) | 1840 |
| Max. Troque Output (N.m) | 50000 |
| Housing Spec.(mm*mm) | 170*140 |
| Ratio | 6.222/5.165 |
| Disc Brake Spec | 22.5" |
| Axle Weight(Kg) | 920 |
| Matching Model | 12~25M Bus |
| 1. Carrier Assembly offsetted, Down Gear Box besides Wheel, enables One-Step-On of afterbody of Large Sized Buses. |
| 2. Joint Developed with S&T Dynamics Co., Ltd., Korea, secures Reliability and Low Noise. |
| 3. High Drive Efficiency, Low Weight, Economic Fuel Consumption. |
| 4. Wide Range of Ratio, Optional Ratio according to different demand. |
