Model:SPA,SPB,SPC,A,B,C,D
Send Inquiry
Specifications
Excellent operational safety
Optimal running characteristics
Equal power transmission
Abrasion-resistant cover fabric
Univer
v-belt pulley:
productin Type | topwidth | pitchwiath | height | angle | length conversion | lengrange | length range(mm) | factory mark |
| Z | 10 | 8.5 | 6 | 40 | Li=LW-22 | 13¨-120¨ | 330-3048 | Li |
| A | 13 | 11.0 | 8 | 40 | Li=LW-30 | 14 ¨-394¨ | 356-10008 | Li |
| AB | 15 | 12.5 | 9 | 40 | Li=LW-35 | 47¨-394¨ | 1194-10008 | Li |
| B | 17 | 14.0 | 11 | 40 | Li=LW-40 | 19¨-600¨ | 483-15240 | Li |
| BC | 20 | 17.0 | 12 | 40 | Li=LW-48 | 47¨-394¨ | 1194-10008 | Li |
| C | 22 | 19.0 | 14 | 40 | Li=LW-58 | 29¨-600¨ | 737-15240 | Li |
| CD | 25 | 21.0 | 16 | 40 | Li=LW-61 | 47¨-394¨ | 1194-10008 | Li |
| D | 32 | 27.0 | 19 | 40 | Li=LW-75 | 80¨-600¨ | 2032-15240 | Li |
| E | 38 | 32.0 | 23 | 40 | Li=LW-80 | 118¨-600¨ | 2997-15240 | Li |
| F | 50 | 42.5 | 30 | 40 | Li=LW-120 | 177¨-600¨ | 4500-15240 | Li |
wedge wrapped v belt
| Production | Top width | pitch | height | angle | length conversion | lengthrange(inch) | length range(mm) | factory mark |
| 3v | 9.5 | 8.0 | 40 | La=Li+ 50 | 16¨-200¨ | 406-5080 | Li | |
| 5v | 16.0 | 13.5 | 40 | La=Li+ 82 | 44¨-394¨ | 1100-10008 | Li | |
| 8v | 25.5 | 23.0 | 40 | La=Li+ 144 | 75¨-600¨ | 1905-15240 | Li | |
| spz | 10.0 | 8.5 | 8.0 | 40 | La=Li+ 50 | 16¨-200¨ | 406-5080 | Li |
| spa | 13.0 | 11.0 | 10.0 | 40 | La=Li+ 63 | 23¨-200¨ | 600-5080 | Li |
| spb | 17.0 | 14.0 | 14.0 | 40 | La=Li+ 88 | 44¨-394¨ | 1100-10008 | Li |
| spc | 22.0 | 19.0 | 18.0 | 40 | La=Li+113 | 71¨-600¨ | 1800-15240 | Li |
