Brand:DAYANG
Model:API wellhead
wellheads and Christmas trees
wellheads and Christmas trees
1.wellheads and Christmas trees suitable for land and offshore applications to explore, develop and produce oil.
wellheads and Christmas trees
2.We design, manufacture, test and control these products in accordance with API 6A, latest edition and also hold a Certificate of Authority to use the API monogram for API 6A products. The main pressure-containing parts of these products are made from forgings or specially smelted low alloy steel (stainless steel) casings for high bearing strength.
wellheads and Christmas trees
3.Wellheads manufactured by our company are available in pressure rating up tof105MPa, load rating up to 500 tons, material classes from AA through FF, temperature classes from L through V, product specification levels from 1 through 4 and PR1 & 2, and also meet NACE Standard MR0175.
wellhead and Christmas trees
wellheads and Christmas trees
Item | Component | Qty | Material | Remark |
1 | Pressure Gauge | 4 |
|
|
2 | Needle Valve | 4 |
|
|
3 | Bull Plug | 1 | 4130 |
|
4 | Casing Head Housing | 1 | 4130 |
|
5 | Threaded Gate Valve | 1 |
|
|
6 | Casing Spool | 1 |
|
|
7 | Flanged Gate Valve | 11 |
|
wellheads
Parameter | Type | |||||||
KQ65/21 | KQ65/35 | KQ80-65/35 | KQ65/70 | KQ78-65/70 | KQ65/105 | KQ78-65/105 | ||
Rated Pressure | 3000psi | 5000psi | 5000psi | 10000psi | 10000psi | 15000psi | 15000psi | |
Nominal Size | Main | 2-9/16″ | 2-9/16″ | 3-1/8″ | 2-9/16″ | 3-1/16″ | 2-9/16″ | 3-1/16″ |
Side | 2-9/16″ | 2-9/16″ | 2-9/16″ | 2-9/16″ | 2-9/16″ | 2-9/16″ | 2-9/16″ | |
Working Temperature | P U | |||||||
Available Medium | Crude Gas | |||||||
PSL | PSL1-3 | |||||||
Material Class | AA-FF | |||||||
PR | PR1-2 | |||||||
Connection Type | Clamp,Flanged | Flanged | ||||||
