KT-393C Copy Router for AluminiumThe machine adopts the half-automatic control copy operation, with big process size and high accuracy. It is fit for the through-hole copy machining of different size of aluminum alloy curtain wall and window profiles. Utilizes the mold and copy the shape of the hole to the workpiece as per 1:1 ratio.MAIN TECHNIQUE PARAMETER1.Worktable size (L*W)....................620*260mm2.Max. distance of milling head from left to right...........240mm3.Max. distance of milling head from front to rear...........120mm4.Max. space height of milling head.......200mm5.Milling cutter diameter in common.......D8mmoptional...........D3~D5mm6.Milling cutter rotation speed...........12000r/min7.Motor power.............................N=1.1KW8.Motor rotation speed....................2830r/min9.Cylinder feeding travel.................50mm10.Working air pressure...................0.6~0.8Mpa11.Overall dimension (L*W*H)..............720(2520)*800*1500mm12. Weight................................250KG
