Folding Spring Bolt-FKB series

Part No.FKB	Suitable for clevis	d1 h11	g	a	b	l1	l2	l3	Mass [kg] 100 pieces
4 x 8	G 4 x 8	4	8	9.5	11.1	19	15	4.5	0.145
5 x 10	G 5 x 10	5	10	12	13.7	23	19	5.5	0.254
5 x 20	G 5 x 20		20		13.8	33	29		0.31
6 x 12	G 6 x 12	6	12	14	16.2	28	23	6.5	0.458
6 x 24	G 6 x 24		24		16.3	40	35		0.516
8 x 16	G 8 x 16	8	16	19	21.6	37	30	8	1.059
8 x 32	G 8 x 32		32		21.6	52	46		1.155
10 x 20	G 10 x 20	10	20	23	26	46	38	10	1.938
10 x 40	G 10 x 40		40		26.3	66	58		2.046
12 x 24	G 12 x 24	12	24	28	31.1	53	45	12	3.306
12 x 48	G 12 x 48		48		31.2	78	69		3.5
14 x 28	G 14 x 28	14	28	31	34.1	62	52	14	4.722
14 x 56	G 14 x 56		56		34	92	82		5.076
16 x 32	G 16 x 32	16	32	36	39.5	73	62	16	6.94
16 x 64	G 16 x 64		64		39.2	103	92		7.44
20 x 40	G 20 x 40	20	40	45	50	87.5	71.5	16	13

  -Material:
   Bolt,low carbon steel 1020,
   Feather,spring steel 65Mn,quenched
   Alternative,stainless steel 304 or 316
  -Surface protection
   phosphatized,oiled,zinc plate, passivated in white-blue or yellow.
