CGF8/8/3type PET bottle Washing / filling / capping three in one machine is one of advanced models which is our company combines international advanced self-filling process and technology developed specifically for mineral water, pure water and other non-gas beverage filling installation.

Constitutes of the equipment:
__. Washing part
__. Filling part
__. Capping part
__. Gas power part
Machine body __electric part
__. Electric box part
__. Work platform
__. Main transmission
__. Chain box and pass in and out arc board
__. frame

Characters of equipment:
1 Direct connection technology between air conveyor and in-feeding starwheel is applied to replace in-feeding screw and conveying chain to ease bottle changing process with only to change few parts. Newly-designed bottle-separating grippers are assembled to starwheel.
2 We adopts Neck-hanging technology in bottle transportation. Instead of traditional starwheel, we use neck-hanging gripper to make bottle-size-changing easily, without equipment height adjustment, only few parts need to be adjusted
3 Specially-designed rinser grippers which are made of stainless steel are firm and endurable, with no contact to screw part of the bottle to prevent second pollution.
4 High-speed, easily-cleaned filling valves with big flow volume are equipped with well CIP system and control system to rinse the equipment thoroughly.
5 Splint of starwheel using twist descending way to simplify the process of bottle-size-changing. only need to change arch board and starwheel, within ten minutes

Parameters:

Production: 1000-3000 b/h
Bottle type: Bottle diameter Φ 50 ~ 100 mm; Bottles of 150 ~ 320 mm high
Cap type: Standard plastic cap
Washing pressure: 0.18~0.25Mpa
Washing water: 0.5T/h
Washing time: 3 seconds
Air Pressure: 0.4Mpa
Air consumption: 0.4m3/min
Main Motor: 1.5KW
Hopper motor: 0.18KW
Washing pump: 0.37KW
Into pump: 0.55KW
Weight: 2100kg
Dimensions: 1780*1680*2200(mm).
