Din female cable(Mini Din cable) assembly

Specifications

This is the older style large, 5 pin keyboard cable.

1. 4C,28AWG (7*0.12mm), Al/Mylar Foil Shielded w/26AWG Drain Wire ( 7/0.15mm), black PVC Jacket
2. Black Molded PVC Hood
3. Din4 Male w/Gold Plating Contacts

Features:
Conductor: Tin copper, 10+10/0.10mm or 10+20/0.10mm, 28AWG
Insulation: PVC
Color: Black/White/other color
Thickness: 0.4mm,
Diameter: 1.0±0.1mm
Shield: Tin copper ,10/0.10mm or 20/0.10mm
Jacket: PVC, Non migration against ABS, Lead free
Length: 1.2m and other length are available

Electrical:
Testing: 100% open & short test
Contact Resistance: 30 MΩ Max
Voltage rating: AC/DC 125V
Current rating: AC/DC 1A
Withstanding Voltage: AC 250V/1 min
Insulation resistance: 100 MΩ Min
Working Temperature: -25~+85

Mechanical:
Insertion Force: 35 N Max
Withdraw Force: 10 N Min
