Model:JM45*2*400
Send Inquiry
Hose Production Line
Specifications
Double layer hose production line
Raw material: PP/PE
Blow vacuum adsorsption forming
Cycle water technology
Hose Production Line is stable strong in resist the internal pressure
High take-up speed
Large output
Hose Production Line canbe widely used in water-saving irrigation project
Main Technical Parameters
| Model | Unit | SJ45*2*400 |
| Suitable Material | LDPE LLDPE HDPE PP | |
| Max Film Width | MM | 200 |
| Film Thickness | MM | 0.08-1.5 |
| Max Output | KG/H | 60-80 |
| Total Power | KW | 32 |
| Machine Dimension | MM | 6000*2000*3800 |
| Screw Diameter | MM | Ø45*2 |
| Screw L/D Ratio | L/D | 30:1 |
| Screw & Barrel Material | 38 CrMoALA | |
| Die-Head Diameter | MM | 80 |
| Heating Power | KW | 9 |
| Main Motor Power | KW | 7.5*2 |
| Inverter | KW | ABB |
| Width of Take-up Roller | MM | 400 |
| Take-up Speed | M/Min | 1-20 |
| Take-up Motor Power | KW | 1.5 |
| Rewind Roller Width | MM | 400 |
| Max. winding Diameter | MM | 600 |
| Winding Motor Power | Kgf.cn | 600 |
