CZ-F300 Hologram Image Coating/Laminating Machine

CZ-F300 is designed for manufactures of laser holographic industry to form a complete set of hard embossing product line.

CZ-F300 is designed for manufactures of laser holographic industry to form a complete set of hard embossing product line. It is well received since been put into production in 1996. It has the following functions and advantages:1.The design of C-shaperoaster reduces the overall size and ensure 5.5m dry journey of film and thus reduces the area take up and improves heating efficiency.2.heating tubes installed on the lower fan room with cooling rib thoroughly reduce heating trouble and improve its security. 3.Applied to single-color gravure and coating materials on clockwise or counter-clockwise.4. Overhung model on unwind and rewind system being adopted even through it is put against the wall, it can adjust the tension with ease and accurately move the film station. 5. Heating controller without contact ensures long life and no noise. 6. It is suitable for coating and dry combining of all materials less than 280 mm breadth.

TechnicalParameter

Rated voltage: 380V±10%
Rated power: 11KW
Coating width: ≤280mm
Coating speed: 210Mmin
Roaster temperature: ≤90
Overall size: 2200×800×1800mm
Weight: 600KG
