Technical parameters:

Engine: Honda OHV4-stroke cooled gasoline engine

Drive System: Automatic hydraulic stepless transmission system

Making speed :0-4km / h

Climbing Degree: 15 degree

Heating method: liquefied petroleum gas

Paint Capacity: 200kg (50L)

Glass beads Capacity: 15kg

Marking Width: 100mm/150mm/200mm/300mm

Weight: 220kg

Dimensions(L*W*H): 1200mm * 900mm * 1000mm

Main features: It adopts scorching quality, Anti high temperature , anti-oxidation special steel stamping Soup base, imported energy-efficient stoves, can be directly melt the paint in paint bucket, a single heat melt is 2 times than an ordinary thermoplastic marking machine, CVT drive system which saving manpower meanwhile greatly improved efficiency of construction.

Structural features: The machine adopts cast aluminum alloy hopper warehouse with high mass sensitivity, high stability; floor knife imported  Cutter hard tungsten alloy, anti-adhesive wear; structure is rugged and simple, flexible operation, close freely, to ensure that the designated marking trimming, end-butt, coating evenly and line appearance well. Glass beads spray device synchronized with the paint scraper clutch deposition systems and spray quantitative. Rubber wheel adopts plastic casting steel wheels, special high temperature and anti-wear rubber .

Main application :

It is the key equipment during thermoplastic marking  construction , equipped with Thermoplastic kettle. Apply for highways, urban roads and hot melt Reflex marking such as  straight line, dotted line, curves, arrows, text and other designated facilities.
