CNC-602A Injector Cleaner & Tester

Product ID: CNC-602A

Brief Introduction:

Developed with the technology of ultrasonic cleaning and fuel pressure control, Launch injector cleaner & tester CNC-602A is an advanced electromechanical product, which can clean and test injectors by simulating engine working conditions. It can also perform cleaning on the injectors and fuel supply system on vehicle.

Feature:

 With dynamic ultrasonic cleaning technology applied, it can perform thorough cleaning in two alternative working modes to bring ultrasonic cleaning into full play.

 With automatic control and digital technology, it can give total control to cleaning and testing through monitoring major parameters in different working conditions.

 9 incorporated functions: Ultrasonic cleaning, on-vehicle cleaning, back-flush cleaning, flow uniformity test, leak test, flow pattern test, injection test, minimum pulsed flow test and auto cleaning test.

 Adjust pulse width and speed at anytime and test the minimum pulsed flow of the injector.

 Drain demo oil at anytime during cleaning.

 Test and clean single-point injectors such as TBI, CFI, ECI and CIS and multi-point injectors.

 User-friendly key board, easy to view and operate.

Specification:

 Ambient temperature: -10ºC~40ºC

 Relative humidity: <85%

 Environment magnetic intensity: <400A/m

 Power: AC110V~220V 50Hz/60Hz

 Input power: 450W

 Ultrasonic cleaning power: 110W

 Range of pressure adjustment: 0~0.65MPa

 Length of pressure adjustment: 0.004MPa

 Range of sumulating test: 10~9990rpm

 Step length of simulating test: 10rpm

 Counting range: 1~9999 times

 Timing range: 1~9999 seconds

 Range of pulse width: 0.5~25ms, step length 0.1ms

 Volume: 2500ml

 Dimensions: 380mm x 390mm x 450mm

 Weight: approx. 25kg
