| Googol QTA4320 diesel engine, output range is from 1643kW to 2379kW,1500rpm | |
| Engine Model | QTA4320-G1 |
| Speed (rpm) | 1500 |
| Frequency (Hz) | 50 |
| Engine Standby Output (kW) | 1800 |
| Engine Prime Output (kW) | 1643 |
| Fan Reduction (kW) | 40 |
| Net Standby Output (kW) | 1760 |
| Net Prime Output (kW) | 1603 |
| Standby Electrical Generation Output (kVA) | 2090 |
| Standby Electrical Generation Output (kW) | 1672 |
| Prime Electrical Generation Output (kVA) | 1903.75 |
| Prime Electrical Generation Output (kW) | 1523 |
| Typical Alternator Efficiency | 95% |
| Typical Power Factor | 0.8 |
| Basic Performance Datasheet | |
| Aspiration Type | Turbocharged, air-water aftercooled |
| Injection Type | Direct Injection |
| Configuration | Vee |
| No. of Cylinders | 16 |
| Displacement (l) | 70.8 |
| Bore (mm) | 170 |
| Stroke (mm) | 195 |
| Compression Ratio | 13.5:1 |
| Piston Speed (m/s) | 9.75 |
| Rotation Direction (from flywheel) | Counter Clockwise |
| Static Speed Droop | ≤ 5% |
| Flywheel House Size | SAE0-21 |
| Lubrication System | |
| Lube Oil Specification | API-CF4 |
| Oil Capacity (l) | 240 |
| Max. Premissiable Oil Temperature (°C) | 89 |
| Oil Pressure Warning (bar) | 3.2 |
| Oil Pressure Shutdown (bar) | 2.2 |
| Cooling System | |
| Coolant Capacity for Engine (l) | 75 |
| Max. Prenissiable Temperature (°C) | 81 |
| Max. Coolant Warning Temperature (°C) | 84 |
| Max. Coolant Shutdown Temperature (°C) | 89 |
| Thermostat Open Temperature (°C) | 74 |
| Flow of Coolant pump (m³/h) | 49 |
| Fuel System | |
| Governor Type | Electrical |
| Fuel Consumption at 25% of Full Load (l/h) | 111.3 |
| Fuel Consumption at 50% of Full Load (l/h) | 207.0 |
| Fuel Consumption at 75% of Full Load (l/h) | 297.0 |
| Fuel Consumption at 100% of Full Load (l/h) | 375.0 |
| Intake & Exhaust System | |
| Combustion Air Consumption (m³/h) | 8646 |
| Max. Intake Restriction (mbar) | 20.5 |
| Max. Exhaust Temperature (°C) | 512 |
| Max. Exhaust Back Pressure (mmHg) | 76 |
| Exhaust Gas Flow (m³/h) | 26790 |
| Exhaust Flange Diameter (mm) | 250 |
| Electrical System | |
| Charging Alternator Voltage (V) | 28 |
| Charging Alternator Capacity (A) | 35 |
| Starting Voltage (V) | 24 |
| Starting Motor Capacity (kW) | 15 |
| Minimum Battery Capacity (Ah) | 4*150 |
| Engine Dimension | |
| Length (mm) | 3596 |
| Width (mm) | 1459 |
| Height (mm) | 1820 |
| Engine Dry Weight w/o Cooling System | 6250 |
| Note: | |
| 1. All engine parameters are in accordance with ISO3046, ISO8528. | |
| 2. All engine parameters are based on 25°C / 100kPa environment condition. | |
