American type mini clamps
2016-10-28 23:05  Views:241
Price:Negotiable
Model:KMM
Send Inquiry



 Stainless Steel American Type Pipe Clamp

1)Bandwidth: 8mm, Thickness: 0.5mm
2)diameter :6-16mm
3) Installation torque:1.4-1.7N.M ,Ultimate torque:2.3N.M
4)Material:  stainless steel200/300

5)Light weight, low profile, compact design allows ease of installation in space restricted applications.

6)The 5/16” band width generates significant sealing pressure with relatively low installation torque. levels..

KMMxxSSKMMFxxSS
Material for BandAISI 200 Series SSAISI 300 Series SS
Material for HousingAISI 200 Series SSAISI 300 Series SS
Material for ScrewAISI 200 Series SSAISI 300 Series SS
DetailHeat-treated
corrosion resistancegoodbetter
Rated Ultimate Torque20in.lbs. min.(2.3Nm)15in.lbs. min.(1.7Nm)
Recommended Installation Torque12-15in.lbs.(1.4-1.7Nm)10-12in.lbs.(1.1-1.4Nm)



Part Number"A" Diameter Range
SAE Ref."200"Series SS"300"Series SS   MillimetersInches
4KMM4SSKMMF4SS6~161/4~5/8
6/8KMM5SSKMMF5SS8~235/16~29/32
10KMM10SSKMMF10SS14~279/16~1-1/16
