1000m Tactical Field Optic Cable & Kits

This cable kit includes a set length of cable, special connectors, FC connectors and a special design reel for fast distributing and retrieving.

Features:
1. All dielectric high mechanical performance and wide operation temperature range cable.
2. Standard neutral click lock connector, water resistant and dust protecting.
3. Neutral connectors that can direct connect between socket and flanging socket, socket and socket, flanging socket and flanging socket.
4. The orientation pin design ensures fast blind connection, and the precision ferrule makes the interchangeable and repeatable connection better performance.5. Special design reel with automatic cable arranger for fast, easy distribution and retrieving.

Applications:
1. Military field communication system.
2. Live TV broadcasting, oil field, harbors communication.
3. Optical communication line rush repairing.

Specifications:
1. Fiber Count: 2~8
2. Wavelength: 1310nm/1550nm(single-mode fiber)
3. Typical Attenuation: ≤1.0dB@1310nm,≤0.85dB@1550nm
4. Connector Type: Neutral Click Lock
5. Max. Tensile Load: 1500N
6. Crush Resistant: 1000N/100mm
7. Operation Temperature: -45~+85℃
8. Repeated Connecting: ≥1000 Times
9. Kit Size: φ500*460mm
10.Gross Weight: ≤40kg
