Baking free brick making machine
2016-10-28 23:47  Views:226
Price:Negotiable
Model:4-15B
Send Inquiry

Parts of Equipment

Main Machine
Mixer
Conveyor belt
Pallet Conveyor
Pallet Catcher
Electrical Controlling Cabinet
Hydraulic Station
Material Feeder
Second Material Feeder
Mold

Example Brick and Output

 Brick

Specification(L*W*H)

Quantity(pcs/moud)

Output Period

Output (pcs/hour)

standard brick

240*115*53mm
9.4*4.5*2.0 inch

26

20s

4680

bloated brick

100*200*60mm
3.9*7.8*2.4 inch

16

20s

2880

perforated brick

240*115*90mm
9.4*4.5*3.5 inch

14

20s

2520

hollow brick

390*190*190mm
15.4*7.5*7.5 inch

4

20s

720

----

----

----

----



Main Technical Parameters

Vibration Force                68KN
Vibration Frequency        5000times/min
Amplitude                        5mm
Max. Pressure                 10Mpa
External Dimensions       4910*1550*2590mm
Power                             31KW
Weight                            6T

Product Description

1. The device is shock pressure type brick making machine;
2. A number of pieces forming at a time reducing electricity and labor costs;
3. Delivering board, aggregating, vibrating automatedly;
4. Achieving a centralized handling stacking with several pieces out of the mold at one time,    improving production efficiency;
5. The mold can be changed conveniently, fast speed and lower noise.
6. only 10 working panels are in need. Pressed wall bricks and ground bricks can be wet-stacking.
