Small size with manual operation control cabinet, easy to operate, and with double cement mortar prepare, it can produce sidewalk color bricks, varies kind of hollow blocks, border block (maximum size:800x350X150),manifold holes bricks and plant grass bricks, etc.The whole machine is designed reasonable, with simple structure and low cost, consumes as 60% total power as normal, work stable and reliable.The machine has double cement mortar preparing process to get multi-functions, and can produce different cement mortar bricks by replacing the moulds, such as varies kind of hollow bricks, manifold holes bricks, sidewalk color bricks and plant grass bricks, etc.Easy to operate and convenient to maintenances, hydraulic driven, manual send material, and brick shaped quickly, each mould produce four standard 390 × 190 × 190 bricks, 3000 bricks can be produced during one shift (eight hours).
Bricks shaped: 4 bricks / mould
Pump output: 40ml/r
Vibrating force: 80KN
Circle:25-30s
Cylinder diameter: φ80mm
Total power: 13.5kw
Overall dimension: 4400×3900×2500
| Type HMSV-2004C semi-automatic multi-function brick machine |
| Specification | Model | Quantity | power |
|
| Vertical mixer | JS350 | 1 | 7. 50 |
|
| dump skip |
| 1 |
|
|
| Type 2004C main machine | QT＆M4-30 | 1 | 6.00 |
|
| skip |
| 1 |
|
|
| conveyor for brick | 1000 | 1 |
|
|
| conveyor for pallet | 2000 | 1 |
|
|
| Aux mixer | JS250 | 1 | 5.50 |
|
| Hydraulic pump system | 40L | 1 | 5.50 |
|
| Total |
|
|
|
|
| Plant area:250㎡ Curing area:1000㎡ Manpower:10-12 Person Brick producing(8 hours):3,840 bricks（390×190×190） Milti-holes brick:11,000 bricks（240×115×90） brick:23,000 bricks（240×115×53） Support pallet dimension:890×535×20mm(wooden) 890×535×（5-6）mm(Steel) |
