01) Alloy: 1100,1200,1050,1060,3004, 3003, 3005, 3105, 8011, ...
02) Aluminium thickness: 0.06mm~4.0mm
03) Aluminium width: 100mm –3000mm
04) Coil's standard diameter: 1100mm
05) Coil's standard weight: 2000kgs
06) Coating finish: PVDF, POLYESTER, NANO,BRUSHED
07) Gloss:10-90%(EN ISO-2813:1994)
08) Total coating thickness:
PVDF coating: more than 25 micron
Polyester coating: more than 18micron (EN ISO-2360:1995)
09) Coating hardness (pencil hardness) more than 2H
10) Adhesion: 5B (EN ISO-2409:1994)
11) Impact resistance: No cracking and peeling (A.S.T.M D2794-1993)
12) Flexibility (T-bend): 0T- 2T
13) MEK resistance: more than 100
14) Bottom side aluminium sheet is coated with protective polyester material, thickness more than 6 micron
