Dimension L x W x H

4,600 x 1,800 x 1,300   (mm)

Extruding Speed

≈  80  (piece / min. As split tile size 227 x 60 x 12 mm for example)

Degree of Vacuum

≤  - 0.090    (mpa)

Out Put

≈ 1200   (m2/day)

Production Capacity

≈  5-8    (tons / hr )

Extruding Pressure

3.0     (mpa)

Augers Nominal Diameter

ā400 / ā300     (mm)

Power

37  (kw.  Main )     3   (kw. Vacuum Pump )

Weight

≈  4800     (kg)

Standard Set

Mechanical Jacks System: High strength and ultra-thick gears reduction device, etc. Electric Auto-Control System: Frequency converter, electric motor and control cabinet, vacuum pump etc.
