Model:JRL-SP-001
Structure
Core | Conductor | Insulation | Wrap | Outer shield | Jacket | O.D | |
| material | Structure | ||||||
| 5 | Tinned copper spiral | 26AWG(19/0.1) | SRPVC or HDPE | Paper tape | Tinned copper spiral | TPU | 4.0mm |
Characteristics
| Item | Value of Characteristic |
| Conductor Resistance(@20°C) | 150Ω/KM,MAX. |
| Capacitance(f=10kHZ) | 210PF/M(conductor-shield)Max |
| DielectricStrength)(3m0 | 1250V.AC,30secs.(conductor-shield ):5000V,DC,Is(Conductor,shield-jacket)leakage current Less than 0.25mA(3M) |
Flexing test:Angle90weight=500gR=12.5mm 30cycles/min/ | >50cycles |
| Wire Tensil Strength | >15ibs(test single wire) |
| noise(EC53§4.5.4°C) | Less than 50uV) |
| Cable peelability in 180°C peel teat | 0.15~1b(did not damage the wire) |
| Compliance with Rohs requiremment |
Application
Used for ECG signal
Properties
all patient contact materials are latex free and have been tested according to ISO10993-5 and ISO10993-10
Main products
spo2 sensor cable ,ecg cable ,disposable cable ,silicone rubber cable,ESU pencil cable ,therapy cable,PU reel cable and so on We also can make cables according to your requirements.
about us
1Biological compatibility and ISO approved
2competitive price and timely delivery
3Accept sample order and small order
4We also can make products according to your requirements
5"high starting point ,outstanding quality ,superior service"
Application
Used for medical equipent
Properties
all patient contact materials are latex free and have been tested according to ISO10993-5 and ISO10993-1, Anti-Uv,bio-compatibilty.
Main products
spo2 sensor cable ,ecg cable ,disposable medical cable ,silicone rubber cable,ESU pencil cable ,PU reel cable and so on We also can make cables according to your requirements.
about us
1Biological compatibility and ISO approved
2competitive price and timely delivery
3Accept sample order and small order
4We also can make products according to your requirements
5"high starting point ,outstanding quality ,superior service"
payment term
T/T or western Union
