Model:JX-1325S
Stone engraving machine
Model | JX-1325 |
X,Y Axis working area | 1300mm*2500mm |
Z Axis working area | 200mm |
Max. processing Speed | 25m/min |
CPU | DSP/100MHZ |
Interface | USB |
Power(not include spindle) | 1840W |
Spindle power | 4.5kw |
Spindle rotating speed | 0-24000rpm/min |
command | G code*.u00*.mmg*plt |
Work Mode | step motor (servo option) |
Work voltage | 380V/50Hz |
Suitable Industry:
1. Granite, Marble, Bluestone, Sandstone and other stone engraving
2. Hard stone like Granite can be layered engraved to reach 3mm
3. Marble, Bluestone and so on can be engraved to 5mm each time
Performance Characteristics:
1imported Linear Guideway, Double-line Four-row Slider, Undertake Heav-duty, Stable operation,
High precision, Long lifetime.
2The whole machine is made of welding steel, high stiffness, the back table is Steel sheet, heavy-duty up to 1 ton;Constant Output Spindle, Heavy cutting capacity, high efficiency.
3Excellent Compatibility: compatible of TYPE3, ARTCAM, CASTCAM, UCANCAM and other CAD/CAM Design Software.
4The two-way tool cooling system increase the lifetime of tools.
