FEATURES

Charging rate:

80 L/min - 4,8m³/h

Filling time cylinder:

6.8L 0-300bar/25.5min

12L 0-200bar/30min

Working pressure:

225 Bar / 3300 Psi

300 Bar / 4300 Psi

Full load Amp:

14A (230V-50/60Hz)

29A (115V-60Hz)

Driven by:

Single-phase electric motor

Power:

2,2 Kw

Dimensions:

height 35cm, width 65cm, depth 39cm

Dry weight:

39,5 Kg / 87 lbs

Noise pressure:

81,7 dB

Number of stages and cylinders:

4

Lubricating oil capacity:

300 cc (0,3 L) / 10 FL. OZ.

Lubricant:

CE 750

frame:

Powder coated steel

Oil/moisture separator:

After last stage

Filtration:

Filter cartridge activated carbon and molecular sieve

Safety valve:

On the separator housing

Interstage coolers and after coolers:

Stainless steel

Suction filter:

2 micron paper - 25 micron polyester

Breathing air:

EN 12021 CGA E
