Model:GR135
GR135 motor grader
XCMG motor grader
1. Model : GR135
2. Engine:Cummins 6BT5.9-4
3. Operating weight 11000kg
4. Have CE certificate
Model | GR135 | |||
Basic specification | Engine |
| 6BT5.9-C | |
Rated power/speed | KW/rpm | 100/2200 | ||
Dimension(L×W×H) | mm | 8015×2380×3050 | ||
Operating weight(Standard) | Kg | 11000 | ||
Performance specification | Travelling speed,forward | Km/h | 5.8.13.20.30.42 | |
Travelling speed,reverse | Km/h | 5,13,30 | ||
(f=0.75)tractive force | KN | 61.3 | ||
Max.gradeability | % | 20 | ||
Tire inflation pressure | Kpa | 300 | ||
Working hydraulic pressure | Mpa | 16 | ||
Transmission pressure | Mpa | 1.3-1.8 | ||
Operating specification | Max.steering angle of front wheels | ° | ±49 | |
Max.lean angle of front wheels | ° | ±17 | ||
Max.oscillation angle of front axle | ° | ±15 | ||
Max.oscillation angle of balance box | ° | 16 | ||
frame articulation angle | ° | ±27 | ||
Min.turning radius using articulation | m | 6.6 | ||
Biade | Maximum lift above ground | mm | 410 | |
Maximum depth of cutting | mm | 535 | ||
Maximum blade position angle | ° | 90 | ||
Blade cutting angle | ° | 54-90 | ||
Circle reversing rotation | ° | 360 | ||
Moldboard width ×height | mm | 3710×610 | ||
