Detailed introduction to [HUJI] Hollow metal frame Anchor:

APPLICATION  SCOPE

   - Specially used in fastening many kinds of window frame, steel-wood structure, railing and construction decoration(as GRC). This anchor is also the best choice of fixing floor base and other deep components.

PART  DESCRIPION

   - SCREW:steel of C1008a, galvanized, countersunk or pan head screw.
   - SLEEVE:steel belt(thickness δ=0.75±0.05mm), hot-dip zinc plated stamped by auto-mold
   - NUT:zinc alloy or steel of C1008a, galvanized

 FORCE TEST & USES SUGGESTION

 - Fixed on concrete C30 and test pulling force, its destruction force value should be more than 4000N.
 - Suggestion: single perpendicular load force should be less than 2500N
