Material: carbon steel, stainless steel, brass;Surface Treat: galvanize Yellow Zinc, Black Zinc, Cr6 free Zinc, Nickel;Application: widely used in the hydraulic and fluid conveying system of machinery, oilfield, mine, building, transportation, food and other industries.
| HOSE BORE | DIMENSIONS | ||
PART NO. | DN | DASH | D | L |
00110-03 | 5 | 03 | 17.5 | 27 |
00110-04 | 6 | 04 | 20.6 | 30 |
00110-05 | 8 | 05 | 20.8 | 31 |
00110-06 | 10 | 06 | 23.3 | 32 |
00110-08 | 12 | 08 | 27 | 34 |
00110-10 | 16 | 10 | 30 | 37 |
00110-12 | 20 | 12 | 34 | 43 |
00110-16 | 25 | 16 | 42.6 | 50 |
00110-20 | 32 | 20 | 52 | 59 |
00110-24 | 38 | 24 | 58 | 74 |
00110-32 | 51 | 32 | 72 | 78 |
