Diameter Type Weight (Kg)
13mm SKL1 0.49
13mm SKL3 0.53
13mm SKL12 0.53
13mm SKL14 0.505
Material: 60Si2CrA
Loading Property: Under pressure 8-12KN, the displacement is between 9-12mm.
Fatigue Property: No less than 5 million times.

3> PR Clip
Technical Parameter of The PR Clip
Material 60Si2MnA
Bar Diameter 7/8"
Nominal Toe Load 2,000 lbs
Nominal Rail Seat Clamping Force 4,000 lbs
Working Deflection 0.56"
Weight 2.75 lbs

4> Nabla Clip
Material 60Si2MnA
Loading Property 2500DaN
Hardness HRC51~55
After the first two tests, variation of the height after releasing is only 0.45mm and after three more tests, there is only 0.1mm variation of height

5> Vertical Special Rail Clip
Material 60Si2MnA
Loading Property 2500DaN
Hardness HRC51~55

6> Rail Deenik Clip
Material 60Si2MnA
Diameter 16mm
Hardness HRC51~55
