Model:MTQ
Send Inquiry
We are professional manufacturer for coil winding tensioner,We offer Mechanical tensioner, Magnetic tensioner,electronic tensioner and servo tensioner for coil winding machine at competitive price.
Magnetic Tensioner with Cylinder by using permanent magnet, The tension is generated to the damp wheel, The non-contact mechanism design provides stable,consistence and precision tension to the wire,Excellence for both high and normal speed winding.
Model | Applied wire diamiter(mm) | Tension scope(g) |
MTQ100 | φ0.03—φ0.07 | 4.0g—40g |
MTQ200 | φ0.04—φ0.14 | 10g—120g |
MTQ300 | φ0.08—φ0.25 | 50g—400g |
MTQ400 | φ0.12—φ0.35 | 80g—600g |
MTQ500 | φ0.14—φ0.40 | 100g—800g |
