Shot Blasting Machine- Q32 Series Tumble Belt Type - Sell

Shot Blasting Machine- Q32 Series Tumble Belt Type

2016-10-30 14:32 Views:68

Price:Negotiable

Shot Blasting Machine- Q32 Series Tumble Belt Type

This series is used for surface cleaning; rust removing, and surface intensification of each kind of middle and small scale casting, forging and job. It is suitable for different production scale, can be stand-alone use and many units can also be used in conjunction with the continuous conveyor components, composing the production of clean-up lines.

Q32 series abrade cleaning up machine has the advantages of advanced design, reasonable structure small energy consumption and high efficiency.

Sequence item Q326 Q3210 QR3210

Number

1 productivity(T／h) 0.6-1.2 3-5 1.5-2.5

2 loading weight (kg) 200 800 600

3 the maximum weight of one piece (kg) 10 15 30

4 diameter of roller(mm) Ф650 Ф1000 Ф1000

5 available capacity (m) 0.15 0.4 0.3

6 pill impelling volume(Kg／min) 100 250 250

7 dedusting air volume(m3／h) 2200 6000 5000

8 power dissipation (KW) 12.6 32.6 24.3

9 appearance dimension(mm) 3681x1650x5800 3644x2926x5856 3972x2600x4768
