Bucket sand washing machine
2016-10-30 14:40  Views:118
Price:Negotiable
Brand:HengXing
Model:G*2600
Send Inquiry

normal style="MARGIN: 6pt 24pt 0pt 0cm; mso-para-margin-top: .5gd; mso-para-margin-right: 24.0pt; mso-para-margin-bottom: .0001pt; mso-para-margin-left: 0cm">Bucket sand washing machine introduction :

normal style="MARGIN: 6pt 24pt 0pt 0cm; mso-para-margin-top: .5gd; mso-para-margin-right: 24.0pt; mso-para-margin-bottom: .0001pt; mso-para-margin-left: 0cm">The efficient sand washing machine, which are developed on the basis
of introducing foreign outstanding technology of the same kind of products, is
a kind of cleaning equipment of international advanced level for sand and slag,
pellets, Used to remove dust in sand, this equipment can improve sand quality.
Application:
Sand washing machine is widely used for cleaning materials in the following industries:
quarry, minerals, building materials, transportation, chemical industry,
water conservation and hydropower, cement mixture station and so on.
Working Principle:
Driven by electric motor and decelerator, the impeller of sand washing machine moves in a circle in the water groove, thus make the sand or slag pellets mixed, overturned,
cleaned and discharged in the water groove 。

normal style="MARGIN: 6pt 24pt 0pt 0cm; mso-para-margin-top: .5gd; mso-para-margin-right: 24.0pt; mso-para-margin-bottom: .0001pt; mso-para-margin-left: 0cm">Features
1. It is of simple structure. The bearing device of impeller drive is separated from
water and materials with water, to avoid in a large degree that the bearings
are damaged by being soaked with water, sand or some polluted things.

2. Being used for cleaning sand in quarries, it has many advantages compared with
traditional spiral sand washing machine:

There is little loss for medium-sized and fine sand and stone powder. The grade and
the fineness of the sand for construction after being washed can be up to the
national standards, such as sand for construction and cobble and broken stones
for construction.
There are no other wear parts except the screen mesh.
It has longer service life and little maintenance chance.

normal style="MARGIN: 6pt 24pt 0pt 0cm; mso-para-margin-top: .5gd; mso-para-margin-right: 24.0pt; mso-para-margin-bottom: .0001pt; mso-para-margin-left: 0cm">Sand washing machine technical specifications:

normal style="MARGIN: 6pt 24pt 0pt 0cm; mso-para-margin-top: .5gd; mso-para-margin-right: 24.0pt; mso-para-margin-bottom: .0001pt; mso-para-margin-left: 0cm">

normalTable style="BORDER-RIGHT: 1pt inset; BORDER-TOP: 1pt inset; BORDER-LEFT: 1pt inset; WIDTH: 374.25pt; BORDER-BOTTOM: 1pt inset; mso-cellspacing: 0cm; mso-padding-alt: 0cm 0cm 0cm 0cm; mso-border-alt: inset windowtext .75pt; mso-border-insideh: .75pt inset windowtext; mso-border-insidev: .75pt inset windowtext" cellSpacing=0 cellPadding=0 width=499 border=1>

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>Model

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>Capacity(t/h)

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>return sand(t/h)

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>Power(kw)

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>Weight(kg)

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>G×2000

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>8-40

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>3-8

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>4

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>1900

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>G×2600

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>20-100

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>5-15

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>5.5

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>3500

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>G×2800

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>50-130

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>8-70

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>7.5

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>5100

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>G×3200

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>240-300

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>80-130

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>11

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>8800

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>G×3600

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>280-500

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>100-200

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>15

normal style="MARGIN: 0cm 0cm 0pt; TEXT-ALIGN: center" align=center>14200
