Brand:DAYANG
Model:F-500, F-800,F-1000,F-1300,F-1600 mud pump
mud pump
mud pump
we can supply models of mud pump , F-500, F-800,F-1000,F-1300,F-1600
Triplex Mud Pump
the details information as follows ;
Triplex Mud Pump
mud pump
Model | JF-500 | JF-800 | JF-1000 | JF-1300 | JF-1600 |
Type | triplex single acting piston pump | triplex single acting piston pump | triplex single acting piston pump | triplex single acting piston pump | triplex single acting piston pump |
Rated input | 373kw | 596kw | 735kw | 956kw | 1176kw |
Power | 500HP | 800HP | 1000HP | 1300HP | 1600HP |
Rated speed | 165SPM | 150SPM | (140SPM) | (120SPM) | (120SPM) |
Max.liner | 170×254mm | 170×254mm | 170×254mm | 180×305mm | 180×305mm |
bore ×stroke |
|
| 6.6930”×10 | 7.0867”×12” | 7.0867×12” |
Gear type | herringbone | herringbone | herringbone | herringbone | herringbone |
Suction flange | 8”(203mm) | 10”(254mm) | 12”(305mm) | 12”(305mm) | 12”(305mm) |
Discharge flange | 4”-5000psi | 5”-5000psi | 5”-5000psi | 5”-5000psi | 5”-5000psi |
Valve pot | API6# | API6# | API6# | API7# | API7# |
Weightofmain body | 9770KG | 14500KG | 18790KG | 24572KG | 24791KG |
mud pump
