JBG-40K rebar thread rolling machine not only adjusts freely in the range Φ14-Φ40mm using the rib-stripping plate but also eliminates the problem that the rebar head with screw thread often becomes bigger, further guaranteeing the construction quality.

JBG-40D adds the screw pitch angle mechanism. The range of profess isΦ14-Φ40mm and the effective length of the rebar head is 100mm. The diameter of the rebar head is consistent from the top to the bottom. The thread shape is much more smooth and full. It is easier to operate, using one handpiece to process both the right-handed and the left-handed thread, and it is easy to adjust. It is especially fit for the rebar splicing in bredge-piles and tunnel construction as well as the rebar splicing in civilian construction. It can guarantee the construction speed and quality. It is original domestically.

JBG-40E This machine is used to process rebar with dia from Φ14-Φ40mm and the max thread length can reach 200mm. It has the reasonable structure, the reliable performance and it is very convenient to use. The control part adopts the leakage protector and it can effectively keep the normal function of the equipment and guarantee safe.

JBG-50 This machine is used to process rebar with dia from Φ12-Φ50mm and the effective length of the rear head is 110mm. The diameter of the rebar head is consistent from the top to the bottom. The thread shape is smooth and full. It adopts high power motor to transport the power and it could effectively increases the constructin speed. It is original domestically.

The rebar rib-stripping and rolling parallel thread machine series is mainly used to process the ribbed rebar to provide the rebar head with parallel screw thread in construction. It is the key equipment to realize the rebar parallel splicing. It has the following features:

1)It has a wide range of use, processing rebar head of the parallel screw thread of HRB335, HRB400, HRB500 rebar of Φ12-Φ50mm.

2)It has the unique self opening die head. The rebar is clamped only once and the rebar head with screw thread can be processed within about 30 seconds.

3)The professing of the parallel thread adopts cold rolling technology. The rebar head has no false thread. The thread size is precise.

4)The process does not destroy the bottom diameter of the base material. The splicing strength is stronger than that of the parent material.

5)Reasonable design. There is only one handpiece to process left and right-handed thread, which is quite easy to operate and maintain. The cutting tool can be replaced for only 3-5 minutes.
