1. Testing channel: 1-8, can be extended to 128 channels

2. Frequency range: 50 Hz～10 MHz，to meet various metal material testing requirements.

3. Gain: 0 dB ~ 99 dB, continuously adjustable, the work of each file 0.5dB step

4. Phase: 0 ~ 359 °, continuously adjustable,continuously adjustable, precision 1 °

5. Gain ratio: （X/Y）0.1～10.0

6. Testing speed: >300/min

7. Adjustable probe drive rank: 1～8, the real sense multi-function

8. Fast digital / analog electronic balance

9. non-amplitude, unsymmetrical phase alarm region setting

10. Various display: impedance, time base display

11. Digital Filtering: High-pass frequency (0Hz ~ 2000Hz), low-pass frequency (0Hz ~ 2000Hz)

12. Dalayed hardware output alarm, real-time hardware output alarm

13. Sound-light alarm output

14. charging power supply: 110V ~ 220V

15. Capable of delayed marking, fixed length marking, high accuracy up to 0.001S/1MM

16. Automatic balance time: 1～1000 minute

17. Inner or outside clock for choice

18. Able to remove interfering signals from both ends of the tested workpiece.

19. Mass storage of various test procedures and test data

20. Eddy current testing signals playback, and the defects amplitude, phase and digital value measurement

21. Automatically record and display the number and the position of defects.

22. Display modes: solid line and blanking display

23. Blanking display coefficient: 1～100

24. English and Chinese operating languages, on-line help

25. Rectangular coordinate system and polar coordinates background for choices

26. Automatically display the date and time

for more details, welcome to contact me directly
