ISO9001, ISO14001

CE,UL,TUV,ROHS
Pitch:2.5mm,2.54mm,3.5mm,3.81mm,3.96mm,5.0mm,5.08mm,6.35mm,7.5mm,7.62mm,9.5mm,10.16mm,15mm,19mm

Poles:2p-24p

Screw:M2/M2.5/M3/M4/M5, Galvanized  Steel  or Ni Plated Brass

Wire cage: Galvanized  Steel or Ni Plated Brass

Pin Header: Tin Plated Brass.

Housing:PA66.UL94V-0/PBT.UL94V-0

Rated Voltage:250V,300V,650V,700V,750V,1000V

Rated Current:8A,10A,12A,15A,24A,25A,30A,32A,57A,65A,80A,125A

Withstanding Voltage:AC1500V,AC2000V,AC2500V,AC3000V,AC3500V,AC8000V/1min

Wire Range:3-24AWG

Temperature Range:-40°C -+105°C/-30°C -+120°C

Max Soldering:+250°C for 5 sec.

Torque:0.4Nm(3.5lb.in)/0.5Nm(4.4lb.in)/0.8Nm(7.2lb.in)/1.2Nm(10.5lb.in)/2.0Nm(17.5lb.in)/3.3Nm(29.2lb.in)

Strip Length:4-5mm/6-7mm/8mm/9mm/10-12mm/18mm
