• Tailored structure, easy to operate.

• There are many speeds and speed ratios available, which can satisfy most customers formula and processing requirements.

• frame, frame cap and base, looking very nice, are welded and treated by annealing for stress relieving.

• Chilled alloy cast iron roll is abrasion resistant with long service life.

• The speed reducer is the hard-tooth surface gear reducer of Class 6 precision, which has long service life and low noise.

• Perfect emergency stop device can ensure the safety of personnel and equipment.

• The seal structure with special design can eliminate the leaking phenomenon of lubricating oil.

• Stock pan is easy to clean up with dislodging device.

• Human nature designed operating system reduces labor intensity.

• Modular structure offers various structures for customers option.

• The flexible design system can satisfy customers special design requirements within the shortest time.

• A load test running will be made to the assembled equipment in our company to save debugging time for customers.

Model Item

XK100

XK250

XK360

XK400

XK450B

diameter(mm)

100

250

360

400

450

length(mm)

250

620

900

1000

1200

speed(m/min)

5.8

14.9

17.4

19.3

23

Roll speed ratio

1:1.2

1:1.1

1:1.27

1:1 .27

1:1.27

Maximun distance(mm)

4

8

10

10

10

Maximun feeding amout(kg/batch)

1.2

1015

2025

2535

3050

Model

Y100L24

Y200L8

Y225M6

Y280M8

Y280M6

power (kw)

3

15

30

45

55

(r/min)

1420

730

980

740

980

speed ratio

43

35

49.74

38

47.18

Overall dimensions (mm

1000×530×1040

3400×1270×1620

4140×1770×1700

4490×1770×1750

5570×1900×1750

Weight(kg)

6000

4200

5700

8500

10700

Model Item

XK550

XK550D

XK560A

XK560D

XK660

diameter(mm)

550

550

560/510

560/510

660

length(mm)

1500

1500

1530

1530

2130

speed (m/min)

28.6

27.4

27.6

28

30

Roll speed ratio

1:1.29

1:1.29

1:1.2

1:1.2

1:1.05

Maximun distance(mm)

15

15

15

15

15

Maximun feeding amout(kg/batch)

50～60

50～60

50～60

50～60

4.5T/h

Model

Y315L18

Y315L28

Y315M6

Y315L28

JR136-8

power (kw)

90

110

110

110

180

(r/min)

740

740

980

740

735

speed ratio

34.65

36

11.6

35.64

6260×2330×1780

6290×2300×1780

6290×2330×1780

6290×2330×1780

7050×2670×2100

Weight(kg)

20000

20400

20400

20400

49000
