Specification:

HC-SM8-1823   Manual 8 color 8 station spider machines

1)      Worktable size: 20*25 inch (500*650mm)

2)      Max print size:  18*23 inch (450*600mm

3)      Max print speed: 800pcc/H

4)      Max print thickness: 0-20 MM

5)      Print color number: 8

6)      Max height of screen frame: 1.57 inch (40mm)

7)      Max size of screen plate: 21*26 inch (550*680mm)

8)      Drying mode: IR

9)      Wattage of heater: 6KW

10)  Positioning system: Mechanical position

11)  Power source: Manual，without electricity

12)  Lead rail circle diameter: φ1600mm

Features:

1)      8 color screen printing machine with high strength, good rigidity tensile support and full steel design to ensure longer life.

2)      Center vertical shaft type structure design to rotate smoothly, reduce labor intensity.

3)      Screen frame with rotatable arrangement to make operator work alone or cooperate with two or more people, so high efficiency printing come true.

4)      Worktable can be moved around.

5)      Screen plate can also be moved around, the front of screen plate can be fine adjusted up and down, and overprint precision is 0.025mm.

6)      IR dryer make ink dry fast.

Power Supply: 220V/110V, 50/60HZ（For IR dryer）

Standard Certificate: ISO9001-2000

Country of Origin: Guangdong, China

Payment Terms: T.T, PayPal, Western Union or L/C

Lead time: Within 5 days when get buyer’s payment or deposit

Shippment: By DHL, FedEx, EMS, UPS, by air or by sea

Guaranty:　one year

Packing:    by wooden case

Packing size: 1900*1900*1200mm

Packing volume: 4.3 CBM

Gross weight: 550KG
