High Speed Slitting Machine

1.The main motor adopts variable frequency speed regulating.
2.Unwinding tension half automatic control with brake.
3.Rewinding tension half automatic control with magnetic clutch.
4.Automatic meter counting.
5.Slitting of circle knife,even knife.
6.Automatic EPC for unwinding.

Max machine speed : 250m/min
Max web width : 1300mm
Max unwinding diameters : 600mm
Max Rewingding diameters : 450mm
Slitting width : 80-1300mm
Accuracy of EPC : ±1mm
Total power : 7KW
Overall dimension : 3150 x 1950 x 1460mm
