CBE200

Single acting，Double acting

Input signal：4~20mADC (1/2 sprit range available)
Supply pressure：0.14-0.7MPa (140~700kPa)
Stroke:Linear Motion:10~60mm,Rotary Motion:60~90dig
Air connection:Rc1/4, (NPT1/4 option),(Rc1/4, NPT1/8 for gauges
Pressure Gauge for output:0~0.2 MPa,0~0.4 MPa,0~1.0 MPa Option:kPa,psi,bar
Housing Explosion proof: ExIIBT6
Intrinsically safe: ExiaIICT4,T5,T6
Enclosure rating: IP65
Cam Characteristics Linear (EQ% option)
Ambient temperature
Standard: -20~83
Lower Temp.: -50~60
Higher Temp.: 0~100
ExIIBT6: -20~60
EExiaIICT4: -40~50
EExiaIICT5, T6: -40~65 Material:Aluminum Die-casting
Net Weight:2.2 Kgs,2.3Kgs
Linearity:±1.5%F.S
Hysteresis:±1.0%F.S
Repeatability:±0.3%F.S
Sensitivity:±0.2%
Supply pressure effect:0.2% / 0.01MPaVibration Effect:1% / 1G
Air Consumption
(at output pressure of 50%) 6NL/min.
(at supply pressure of 0.14MPa) 15NL/min.
(at supply pressure of 0.4 MPa)
Max. flow capacity 100 NL/min. / 0.14 MPa,200 NL/min. / 0.4 MPa
