Machine Model

JQ1325 glass laser engraving machine

Working Size

1300mm*2500mm

51in*98in (L*W)

Laser Power

100W/150W/180W

Laser Type

CO2 sealed high quality, water-cooling

Driving System

Stepper motor

Cutting Speed

0-40000mm/min (0-1575 inch/min)

Engraving Speed

0-70000Mm/min (0-2756 inch/min)

Resetting Position Accuracy

≤±0.01

Power Supply

220V/50Hz,  110V/60Hz,

Operating Temperature

0-45c

Operating Humidity

5-95%

Min. Shaping Character

English 1.0*1.0mm

Operating System

PCI OR USB (DSP 6535)

Graphic Format Supported

BMP, PLT, AI, DST, DXF

Software Supported

Coreldraw, Photoshop, AutoCAD, Tajima

Machine Dimension

3350*2150*1250mm

131*84*49in

Packing Dimension

3450*2250*1350mm

134*87*52inch

Net Weight

1100kgs
