The pump has features of advanced structure, small volume ,used reliably , preferable exchange and easy maintenance ,etc.

The mud  pump consist power part and hydraulic part. Power part include: frame, small gear shaft, bent axle, crosshead, intermediate rod. Hydraulic part include: hydro cylinder assembly, valve assembly, cylinder liner, piston and suck &bleed manifold.

TECHNICAL PARAMETERS OF MUD PUMP
Model: F-1000
Type: Triplex liner single-action
Input power: 1000 HP
Maximum stroke: 10inches (254mm)
Maximum working pressure: 5,000 psi (35 MPa)
Gear type: integral herringbone
Valve pots: API 6 #
Intake: 12 inches (305 mm)
Discharge: 4 inches (102 mm)
Pulsation dampener Model: KB -75/Capacity: 75.7 liter (20 Gallon)
Relief valve: Model: AQF-II/Discharge size: 3 in
Pressure gauge: Yk-150 0-40MPA

TECHNICAL PARAMETERS OF DIESEL ENGINE
Model: CAT 3512 (Land mechanical)
Rated power: 1250 HP
Rated speed: 1200 rpm
Revolution direction: anticlockwise (face output shaft end)
about scope of supply seeing the attached

TESTING & COMMISSIONING
Install and secure major machinery and miscellaneous equipment
Furnish lube products for testing
Run diesel engine to test transmission devices
