Brand:AOLAI
Model:GYJQ-63-28/220-A
Send Inquiry
Hydraulic Rescue Cutter GYJQ-63-28/220-A
Product Description:
Light weight; large scissors mouth along with strong shearing ability; short time for both opening and closing to accelerate the process of rescue.
Scope of Application:
#1.Rescue for highway, railway traffic accidents, the earthquake disaster, shipwreck and building collapsed
#2.Cut off vehicle parts, metal structure, heterogenic steel pipe, steel plate and so on.
Product Features:
#1.Shearing Blade adopt High-quality Heat-treated Tool steel, with surface anodized, good in wearing resistance
#2.With Protective cover to prevent the splash during shearing, also automatic reset manually valves, can provide safety for the operator
#3.Ergonomically designed, can automatically push the material to the biggest shearing strength of the blade center.
Major Parameter for Hydraulic Cutter | |
Model | GYJQ-63-28/220-A |
Max. Opening Distance of Cutter Edge | ≥220 mm |
Rated Working Pressure | 63Mpa |
Max. Shear Capability | 15 mm(Steel Plate) |
Q235 materials | ф28 mm(Circle steel) |
Max. Cutting Force | 390 KN |
Opening Time without Load（Oil is Supplied by Motor Pump） | ≤25 s |
Closing Time without Load（Oil is Supplied by Motor Pump） | ≤30 s |
Weight (Working Mode) | ≤13 kg |
Dimensions L*W*H | 700*210*165mm |
Packing Dimension | 880*405*240/25kg |
We welcome freinds and customers' inquiry all the time.
We hope to serve you our hydraulic rescue tools for most victims.
