Simple Specification

Spacer Spools in all sizes and pressure ratings suitable for Well Head extension, B.O.P. spacing, and Choke, Kill and Production Manifold applications. Spacer Spools usually have the same nominal end connections. Spacer Spool identification consists of naming each end connection and the overall length. NOV SARA Spacer Spools usually do not have outlets, but customers may specify outlets.

Feature

• Body: in-line or angle.
• End connections: flanged, threaded or weld end.
• Connections: 1”, 2”,3” from ANSI 150# up to API 5000.
• Trim in stainless steel, hard facing or tungsten carbide.
• Profiled trim to provide linear characteristics.
• Adjusting handle to provide continuous control.
• Indicator barrel shows valve setting in 1/64”.
• Valves can be automated with electric or pneumatic actuators.
• Custom engineered microspline trims provide control below Cv+0.01 and maybe interchanged in standard bodies.

Product range
Size                                : As per customer requirement
Pressure Class               : 2000 PSI to 15000 PSI
Material of Construction : As per API 6A / 16A
Service Condition           : General, Sour Services
