Brand:CCPF
Model:3#
Material: Aluminum
Production Method: Forging
Surface: Abrasive blasting
Application: Horse racing
Features:
1, 14 nail holes
2, Toe clip
3, Forged for strength
4, Tempered for durability
5, Deep swedge protect nail head
6, Wider web for support and protection
7, Nail hole pattern follow a line
8, Seated out for sole pressure relief
9, wedged heel enhance break over and assist in preventing run down
Aluminum Horse Racing Plates | ||||
Size | Description | Specification | Weight(g) | Noted |
Length*Width*Thickness(mm) | ||||
3# | Front | 120*110*8 | 75 | Wedged |
4# | Front | 121*116*8.5 | 85 | Wedged |
5# | Front | 120*129*8.8 | 95 | Wedged |
6# | Front | 135*123*8.8 | 100 | Wedged |
7# | Front | 130*142*8.8 | 105 | Wedged |
| ||||
3# | Hinds | 116*110*8 | 75 | Wedged |
4# | Hinds | 116*118*8.5 | 85 | Wedged |
5# | Hinds | 121*129*8.8 | 95 | Wedged |
6# | Hinds | 127*132*8.8 | 100 | Wedged |
7# | Hinds | 135*139*8.8 | 105 | Wedged |
Noted: The wedged degree is 1.5° | ||||
