High Flow Hydraulic Diaphragm Dosing Pump JYT

Flow: 0-10000 lph
Pressure: 10-500 Bar
Power 11KW, 380V /400V, 50Hz / 60Hz
Drive System: Three phases, Anti-explosion motor
Flow Control: Manual operation, Automatic
Material
Pump head: SUS304, SUS316
Diaphragm: PTFE
Valve: SUS304, SUS316
Valve ball: ZrO2, SUS304, SUS316, Ceramic

Features
1. No leakage, maintained conveniently, low noise, durable in use.
2. Measuring precision is better than mechanical diaphragm pump, sealing property is better than piston pump.
3. Matching a stroke adjuster to realize remote automatic controlling.
4. The diaghragm is made from multilayer complex structure to promote the life span, the first layer is Teflon anti-acid diaphragm, the second is EPDM stretch rubber, the third is 3.00 mm thick SUS304 that supporting the iron corn. The fourth is also the EPDM
