Brand:fitow
Model:466
SS 316L sintered powder filter disc
Filter Rating: 0.5~50 microns
Heat resistance
Corrosion resistance
Washability
Sintered Powder Filter Disc Introductions:
1. Sintered powder filter disc is made of stainless steel powder.
2. Sintered powder filter disc keeps high corrosion resistance, good air permeability,high strength, and high filtration precision.
3. Sintered powder filter disc is easy to wash.
echnique parameters
Filtering Level | Filtration Precision um | Maximum Hole Diameter um | Permeability Coefficient 10-12m2 | Permeability m3/h.m2.kpa | Thickness mm | Compression Strength Mpa/cm2 | Bubbling Pressure Kpa |
S9 | 0.2 | 2.5 |
| 1 | 0.6-10 | 3.0 |
|
S8 | 0.5 | 4 |
| 3 | 0.6-10 | 3.0 |
|
S7 | 1.5 | 6 |
| 5 | 0.6-10 | 3.0 |
|
S6 | 2.5 | 10 | 0.09 | 10 | 0.6-10 | 3.0 | 9.16 |
S5 | 5 | 15 | 0.23 | 40 | 0.6-10 | 3.0 | 6.1 |
8 | 20 | 0.91 | 80 | 0.6-10 | 3.0 | 4.6 | |
S4 | 10 | 30 | 1.81 | 160 | 0.6-10 | 3.0 | 2.6 |
S3 | 28 | 60 | 3.82 | 350 | 0.6-10 | 3.0 | 1.8 |
35 | 80 | 7.29 | 500 | 0.6-10 | 3.0 | 1.4 | |
S2 | 40 | 100 | 9.43 | 700 | 0.6-10 | 3.0 | 1.1 |
S1 | 65 | 160 | 15.1 | 1000 | 0.6-10 | 3.0 | 0.66 |
Application
They are mainly applied to the separation and purification of solid-liquid, gas-liquid and gas-solid in the petrifaction, hydraulic manufacturing and medical apparatus and instruments of basic industries.
Applcation:
Polyester filtration,water treatment,oil filtration,pharmaceutical industry, chemical industry,chemical fiber industry and high high temperature media filtration
