Model:CQF
Send Inquiry
The CQF Reinforced Polypropylene Magnetic pump is mainly made of reinforced PP and all flow-Through parts adopt injection mould with resistance to most organic and inorganic acid, alkali and salty solutions, applicable for being exposed outdoor with fine anticorrosive performance of stress corrosion cracking.
CQF PP magnetic pump product range:
Flow: 0.9-25m3/h
Head: 3-32m
Power: 0.01-5.5kw
Temp: <60 degree
Material: PP(Reinforced Polypropylene)
| Model | Flange | Flow (m3/h) | Head (m) | Power (kW) | voltage | |
| Inlet(mm) | Outlet(mm) | (V) | ||||
| 10CQF-3 | 10 | 8 | 0.9 | 3 | 0.025 | 220 |
| 14CQF-5 | 14 | 10 | 1.2 | 5 | 0.12 | 220/380 |
| 16CQF-8 | 15 | 15 | 1.8 | 8 | 0.18 | 220/380 |
| 20CQF-12 | 25 | 18 | 3 | 12 | 0.37 | 220/380 |
| 25CQF-15 | 25 | 20 | 5.4 | 15 | 1.1 | 380 |
| 32CQF-15 | 32 | 25 | 6.6 | 15 | 1.1 | 380 |
| 32CQF-25 | 32 | 25 | 4.8 | 25 | 1.1 | 380 |
| 40CQF-20 | 40 | 32 | 10.8 | 20 | 2.2 | 380 |
| 50CQF-25 | 50 | 40 | 14.4 | 25 | 3 | 380 |
| 50CQF-32 | 50 | 40 | 12.5 | 32 | 4 | 380 |
| 65CQF-25 | 65 | 50 | 25 | 25 | 5.5 | 380 |
| 65CQF-32 | 65 | 50 | 25 | 32 | 7.5 | 380 |
