14/12 horizontal sand gravel pump

Pump parameters

    1. Size range (discharge):4-18inch
    2. Capacity: 10-5000 m3/h
    3. Head: 5-80m
    4. Impeller type: Non-clog (close)
    5. Shaft sealing: Packing/Gland packing & Mechanical
    6. Wet parts material: A05, A07, Steel

Structure features

    Zidong ZG pumps are single casing connected by means of clamp bands and wide
    wet-passage. The wet-parts are made of Ni-hard and high chromium abrasion-resistance
    alloys. The discharge direction of pump can be oriented in any direction of 360°.
    This type of pump possesses the advantages of easy installation and operation, good
    performance of NPSH and abrasion resistance.
